TITAN - light tower 180k lumen
SKU: DWLTITAN
€0.00Price
Excluding VAT
Ultra-high-power diesel light tower delivering 180,000 lumens for large-scale and extreme-duty applications
top of page
Ultra-high-power diesel light tower delivering 180,000 lumens for large-scale and extreme-duty applications
Titan is the most powerful light tower in the Dewaterco range designed for large job sites, infrastructure projects and extreme operating environments where maximum illumination and high electrical output are required.
Equipped with four 320 W LED floodlights, Titan delivers an impressive 180,000 lumens, providing uniform lighting over very large areas. The 8.5 m galvanized hydraulic mast with 350° rotation ensures optimal light coverage and fast setup even in complex site layouts.
Powered by a Stage V diesel engine coupled with a 20 kVA generator, Titan offers high auxiliary power availability for additional equipment. The integrated brushless alternator with AVR guarantees stable voltage output while maintaining high efficiency.
Built for extreme conditions, Titan operates reliably within an ambient temperature range from –40 °C to +50 °C and withstands wind speeds of up to 110 km/h. With a 240 l fuel tank and optimized fuel consumption, it ensures long operating cycles on demanding sites.
Thanks to its road-tow trailer, reinforced stabilizers and advanced safety systems, Titan is the ideal lighting solution for heavy-duty applications such as mining, large infrastructure works, industrial plants and emergency operations.
9300 mq
ILLUMINATED AREA
185.000 lm
LUMEN
8.5 m
HEIGHT
Features
Technical Specifications
Lighting
LED: 4×320 W
Luminous flux: 180,000 lm
Illuminated area: up to 5,000 m² (20 lux) / 9,300 m² (1 lux)
Mast height: 8.5 m (galvanized)
Mast rotation: 350°
Lifting system: Hydraulic
Electrical
Frequency: 50 Hz
Voltage: 230 / 400 V
Rated power output: 20 kVA
Auxiliary power: Available via CEE and Schuko sockets
Alternator: Linz
Voltage regulation: AVR ±5%
Control unit: ComAp LTC80
Generator & Engine
Engine model: Kohler KDI 1903 M
Engine speed: 1500 rpm
Cooling: Liquid
Cylinders: 3
Fuel type: Diesel
Emissions: Stage V
Operating temperature: -40°C to +50°C
Fuel & Autonomy
Fuel consumption: 2.3 l/h (at 50% load)
Fuel tank capacity: 240 l
Autonomy: up to 104 h (at 50% load)
Mechanical & Safety
Wind resistance: up to 110 km/h
Stabilizers: 4 + 1 wheel
Trailer: Road-tow trailer
Tyres: 185/70R13
Bunded base: 110%
Coating: Powder coated
Safety systems: Dusk-to-dawn sensor battery isolator AMOSS trailer safety system
Dimensions & Weight
Size (shipping): 320 × 150 × 250 cm
Weight: 1100 kg
Related Kit
Discover related kit solutions for this product
Details
All you need to know about this product
Products included
Technical Data
Essential specifications and dimensions for installation and selection
Dimensions
Parts and Material List
Model
HP
kW
Inch
Q
(lpm)
0
100
200
400
600
Q
(m³/h)
0
10
20
30
35
50EUS-5.05
0.5
0.5
0.5
H(m)
54.0
0.5
0.5
0.5
0.5
H(m)
54.0
54.0
54.0
54.0
54.0
Specifications
Limits of Use
Ambient Temp.
-5/+40°C (23/104°F)
Ambient Temp.
-30/+50°C (-22/+122°F)
Autonomy
108h
Type
Frequency
50Hz
Key Parameters
Voltage
230 - 400V
Wind Resistance
up to 110 km/h
Materials
Related products
Related accessories
Matching product
Applications
Typical use cases and environments where this product performs best
FAQ
?
What are light towers mainly used for?
Light towers are used to provide reliable temporary lighting for construction sites, road works, industrial areas, events and emergency operations. They ensure safe and efficient work during night hours or in low-visibility conditions where permanent lighting is not available.
?
Are light towers easy to move and reposition on site?
Yes, our light towers are designed with road-tow trailers and stabilizers that allow easy transport and quick repositioning. However, proper setup is essential: stabilizers must always be deployed, the mast must be fully lowered during transport and local regulations for towing and site safety must be respected to avoid damage or instability.
?
Can light towers operate continuously in harsh environments?
Modern diesel light towers are engineered for continuous operation in demanding environments. They are built to withstand wide temperature ranges, strong winds and intensive use while maintaining stable lighting performance and long autonomy, making them suitable for remote sites and extreme working conditions.
Products Comparison
Compare key features and performance across similar models
Features
ILLUMINATED AREA
LUMEN
HEIGHT
TANK
WIND RESISTANCE
RUNNING TIME
MAST
PRICE
DWC TITAN
9300 mq
180000 lm
8.5 m
240 l
200 h
110 km/h
Hydraulic
€0.00
