HYDROFLAT 0.5R - Ultra-low residue dewatering pump
SKU: DWC037S0015
€619.00Price
Excluding VAT
0.5 HP lightweight pump for flat surface drainage – removes water down to 3 mm.
top of page
Compact submersible pump for residue drainage
With a 0.5 HP motor and a 2" outlet, HydroFlat 05R is suitable for ultra-low-level drainage, removing water down to 3 mm. Compact and lightweight, this submersible pump is ideal for draining basements, parking areas and for post-flood recovery. The efficient circumferential cooling system supports continuous operation, while the double mechanical seal and semi-open impeller ensure durability even with abrasive liquids.
Features
Hight resistance to abrasive liquids
Compact & Lightweight design
Puddle or residue drainage down to 3mm
Efficient circumferential cooling for continuos duty
Related Kit
Discover related kit solutions for this product
Details
All you need to know about this product
KLIXON 1PH thermal protector
Klixon® automatic motor protectors (AM series) are small, light weight and sensitive to temperature and current. The sealed steel cases will stand most dip and bake processes and can be mounted directly on motor windings for fast detection of temperature changes.
Impeller in DuPont™ Hytrel®
Steel coated with a polyester-based thermoplastic elastomer (TPE-E), combining the mechanical strength of steel with the flexibility, chemical resistance and corrosion protection of the elastomer. This coating is ideal for use in humid or aggressive environments where durability and protection against impacts and abrasion are essential.
Products included
Technical Data
Essential specifications and dimensions for installation and selection
Dimensions
HEIGHT
347
mm
MAXIMUM DIMENSION (WIDTH)
214
mm
LOWER RUNNING WATER LEVEL
52
mm
DISCHARGE
2
"
WEIGHT
12
kg
Parts and Material List
2
Handle
Steel + NBR
3
Motor Cover
ADC12
4
Bracket
Steel
5
Motor Housing + Stator
ADC12+Steel
6
Shaft with Rotor
AISI 410
7
Oil Chamber
ADC12
8
Mechanica Seal
Upper:CA/CE
Lower:SIC/SIC
11
Impeller
Hytrel
10
Lip Seal
NBR
12
Pump Casing
EN-GJL-200
15.1
Upper Bearing
NTN/TPI
15.2
Lower Bearing
NTN/TPI
16
Strainer
NBR
17
O-rings
NBR
18.1
Gasket
NBR
18.4
Volute Liner
NBR
30
Outer Housing
AISI 304
32
Pump Casing Ring
AISI 304
Model
HP
kW
Inch
Q
(lpm)
0
100
200
250
300
Q
(m³/h)
0
6
12
15
18
HYDROFLAT 05R
0.5
0.37
2"
H(m)
11
8.7
1.7
-
-
H(m)
11
8.7
1.7
-
-
Specifications
Limits of Use
Liquid Temp.
0/40°C (32/104°F)
Submersible depth
10m
Type
Frequency
50Hz
Motor
2P (2850RPM) . Dry Motor
Insulation
Class B
Protection
IP 68
Protector
Auto-Cut
Bearing
Ball Type
Mech. Seal
Double Mechanical Seal
Impeller
Semi-Open Impeller
Key Parameters
Materials
Related products
Related accessories
Matching product
FAQ
?
What is the main feature of HydroFlat pumps?
They are designed for ultra-low residue drainage down to 3 mm.
?
Where are they most commonly used?
Perfect for basements, parking lots, public works, and flood recovery.
?
Are they compact and lightweight?
Yes, they are easy to transport and install even in tight spaces.
?
Do they withstand abrasive liquids?
Yes, thanks to high-resistance materials and double mechanical seals.
CE Marking: Certified Safety and Compliance
All our products proudly bear the CE marking, a declaration that they meet the essential requirements of European health, safety, and environmental protection legislation. This certification ensures that every pump has undergone rigorous assessment and complies with applicable EU directives. Choosing CE-marked equipment means choosing reliability, legal conformity, and peace of mind—whether for industrial, construction, or professional use.
Spare Parts
Spare parts are always available and can be ordered through an intuitive and efficient system of catalogued diagrams, ensuring full compatibility with each machine. Contact us for assistance!
After Sale Support
For our Dealers, a telephone technical assistance system is set up to perform any maintenance intervention.
